Why VALSTEER Pneumatic Ball Valve?
Complete valve–actuator–accessory packages built for industrial duty.
Fast, Reliable Quarter-Turn Operation
Rack-and-pinion pneumatic actuators deliver quick open/close action with consistent torque across the stroke for clean on/off automation.
Double-Acting & Spring-Return Options
Available in double-acting and single-acting (spring-return) versions, allowing you to choose fail-open or fail-close behaviour based on process safety.
Complete Automation Package
Valves can be supplied with actuator, solenoid valve (SOV), air filter regulator (AFR), limit switch box, fittings and tubing – ready to install and wire.
ISO Mounting & Modular Design
ISO 5211 mounting and NAMUR interfaces make maintenance, actuator replacement and accessory upgrades straightforward.
Tested Assemblies
Each assembly is function-tested for travel, stroke and leakage before dispatch to reduce commissioning issues at site.
Project Documentation Support
Datasheets, actuator and SOV wiring diagrams and, where required, test reports and basic ITP/QAP support for project documentation.
Pneumatic Ball Valve Range
Choose the actuation mode and connection style that suits your line.
Double-Acting Pneumatic Ball Valves
Phoenix ValSteer is a pneumatic ball valve exporter in India supplying double-acting pneumatic ball valve assemblies for industrial applications. Each package combines a stainless steel or carbon steel ball valve with a rack and pinion actuator sized for the required torque, providing fast cycling, repeatable shut-off and long service life under high operating pressures.
In a double-acting configuration, compressed air is used to both open and close the valve, giving controlled movement in both directions. The fail position is defined by the control system rather than by a spring, so double-acting pneumatic ball valves are suitable for high-cycle on off duties, batching lines and automated manifolds where air consumption and actuator size must be optimised.
VALSTEER assemblies are built around ISO 5211 mounting and NAMUR accessory interfaces and can be supplied with solenoid valves, air filter regulators, limit switch boxes and positioners where required. All packages are engineered and tested to relevant API, ASME and ISO standards and can be documented with datasheets, torque calculations and test reports for oil and gas, chemical, water treatment, power and other process industry projects.
Air-to-open / air-to-close operation for frequent cycling and fast, reliable on/off control.
Applications
- General process and utility isolation
- Chemical dosing manifolds
- OEM skid-mounted systems
Best For
- High cycle frequency
- Situations where fail position is not critical or is managed by controls
Single-Acting (Spring-Return) Pneumatic Ball Valves
Phoenix ValSteer is a pneumatic ball valve exporter in India supplying single-acting spring-return pneumatic ball valve assemblies wherever a defined fail-safe position is required. In this configuration, air pressure moves the valve in one direction and a calibrated spring drives it back to a preset safe position when the air supply is lost, with the valve configured as either fail-closed or fail-open according to process design. This makes spring-return pneumatic ball valves a key element in safety and interlock systems handling flammable, toxic or high-energy media.
Each assembly combines a soft- or metal-seated ball valve, typically in stainless steel or carbon steel, with a spring-return rack and pinion actuator sized with appropriate torque margin for the service pressure and temperature. Actuator housings and springs are specified for industrial environments, with corrosion-resistant finishes and reliable travel back to the fail position over many cycles. Packages can be supplied with matched accessories such as solenoid valves, air filter regulators and limit switch boxes to match the site control philosophy.
Single-acting pneumatic ball valves are used on pump discharge lines, chemical injection points, gas and fuel skids and critical utilities in oil and gas, chemical, power and water treatment plants. Each package is engineered and documented to relevant API, ASME and ISO standards so it can be integrated cleanly into plant safety and control systems.
Spring-return actuators that move the valve to fail-open or fail-close position on air failure.
Applications
- Safety and interlock functions
- Air failure / emergency shutdown scenarios
- Lines where a defined fail position is mandatory
Best For
- Safety-critical and interlocked services
- Applications requiring a predictable fail-safe action
Threaded & Flanged Pneumatic Ball Valves
Phoenix ValSteer is a pneumatic ball valve exporter supplying both threaded and flanged pneumatic ball valve packages to suit different piping standards and installation constraints. Threaded pneumatic ball valves are typically selected for small-bore lines and skid systems where space is limited and quick installation is required, while flanged pneumatic ball valves are preferred for plant piping where robust bolting, easy removal and standard flange interfaces are important for maintenance and long-term reliability.
Threaded end valves are commonly used on utilities, dosing lines and manifolds, and flanged designs are supplied for pressure classes such as ASME Class 150 to Class 1500 depending on service conditions. Body materials can be supplied in stainless steel or carbon steel, with duplex and other corrosion-resistant alloys evaluated for aggressive media and project specifications. Seats are selected to match pressure and temperature limits and to maintain tight shut-off over repeated cycling.
Assemblies can be supplied with double-acting or spring-return pneumatic actuators and configured with solenoid valves, air filter regulators and limit switch boxes for remote operation and position feedback. Phoenix ValSteer supports EPCs and OEMs with selection guidance and documentation aligned with relevant API, ASME and ISO requirements.
Screwed/threaded or flanged ball valves with pneumatic actuators for different piping standards.
Applications
- Threaded stainless ball valves for small-bore utilities
- Flanged valves for process lines and higher sizes
Best For
- Matching plant piping standards (BSPT/NPT/flanged)
- Simplifying installation on existing lines
Accessory Packages
Accessory packages turn a pneumatic ball valve into a complete, site-ready automation unit, with control, air preparation and position feedback configured as one package. Phoenix ValSteer supplies matched accessory sets so the valve, actuator and instruments work together reliably and integrate cleanly with your PLC or DCS.
For control, we offer solenoid valves suitable for remote on off operation, selected with the required coil voltage and interface. For stable actuator performance, air filter regulators are provided to condition and regulate instrument air, improving response consistency and extending seal life. For feedback and monitoring, limit switch boxes provide open and close confirmation for interlocks, alarms and panel indication, reducing commissioning effort and troubleshooting time.
Where required, packages can also include speed controllers for adjustable stroking time, quick exhaust valves for faster operation, position indicators, as well as tubing, fittings and mounting hardware for a neat installation. Each accessory package is selected based on duty cycle, air supply, control philosophy and site conditions, and can be supported with datasheets and wiring details for project documentation.
Configured with SOV, AFR, limit switch box and fittings as a complete automation kit.
Applications
- Panel-controlled and PLC-controlled systems
- Projects needing pre-engineered valve automation packages
Best For
- Reducing site engineering and assembly time
- Ensuring compatibility of all automation components
Technical Specification
Key parameters for VALSTEER Pneumatic Ball Valve assemblies.
| Specification | Details |
|---|---|
|
Valve Type |
2-way quarter-turn ball valve, full or reduced bore (depending on series) |
|
Size Range |
Typically ½″ to 2″ for threaded; larger sizes available in flanged designs as per range |
|
Body Material |
Stainless steel (e.g. SS304 / SS316) and carbon steel; other materials on request depending on base valve |
|
Seat Material |
PTFE, R-PTFE or other engineered seats depending on pressure, temperature and media |
|
End Connections |
Screwed/threaded (BSPT / NPT) and flanged as per valve design and standard |
|
Actuator Type |
Rack-and-pinion pneumatic actuator, double-acting or single-acting (spring-return) |
|
Air Supply Pressure |
As per actuator model; typical industrial ranges provided in datasheet |
|
Control Options |
On/Off with solenoid valve; modulating possible on selected combinations with positioner (if you choose to offer it) |
|
Mounting Interface |
ISO 5211 actuator mounting; NAMUR interfaces for solenoid and accessories (where applicable) |
|
Accessories |
Solenoid valve (SOV), air filter regulator (AFR), limit switch box, fittings and tubing as configured |
|
Testing |
Valve hydro/seat testing as per relevant standards; functional stroke testing of assembled package |
|
Documentation |
Valve datasheet, actuator and SOV datasheet, wiring diagram and basic installation guidelines |
Control & Accessory Options
Configure pneumatic ball valves to match your control philosophy and panel design.
Solenoid Valves (SOV)
NAMUR or inline solenoid valves for air-on / air-off control from PLC or local pushbuttons. Available in common voltage options as per project requirement.
Air Filter Regulator (AFR)
Filter regulator units to supply clean, regulated air pressure to the actuator, improving reliability and actuator life.
Limit Switch Box
Mechanical or proximity-type limit switch boxes for open/close position feedback to PLCs, indicators and control panels.
Fittings & Tubing
Pre-selected fittings, tubing and accessories for neat, standardised air piping between AFR, SOV and actuator.
Positioner
On selected packages, a pneumatic or electro-pneumatic positioner may be used for modulating service as per control requirements.
Valve & Material Options
Match pneumatic actuation to the right ball valve construction.
Stainless Steel Ball Valves
SS304 / SS316 ball valves for water, utilities, chemical dosing and general process applications where corrosion resistance is required.
Carbon Steel Ball Valves
Carbon steel options for suitable media and non-corrosive services in process and utility lines.
Threaded Ball Valves
Compact stainless threaded ball valves for small-bore lines, ideal for pneumatic actuation in skids and tight spaces.
Flanged Ball Valves
Flanged ball valves for higher sizes and more demanding process lines where flanged piping is standard.
Special Materials
Special alloys and trims can be considered where process conditions require them and underlying valve designs are available.
Applications & Industries
Pneumatic ball valves for fast, reliable on/off automation in industrial service.
Water & Wastewater Treatment
Automated isolation and control on raw water, filtered water and treated water lines, as well as chemical dosing circuits.
Chemical & Process Plants
On/off control on chemical transfer, utility lines and dosing systems where compact automation is required.
OEM Skid Packages
RO systems, softeners, ETP/STP units, boilers, chillers and other packaged equipment requiring pre-assembled automated valves.
Food & Beverage / Pharma Utilities
Utilities such as water, glycol and clean services where pneumatic actuation is preferred over electric for safety or environment.
Industrial Utilities
Compressed air, nitrogen and plant water distribution lines with centralised PLC/BMS control.
HVAC & Building Services
Chilled water and condenser water lines where pneumatic actuation is integrated with building management systems (if you choose to serve this segment).
Pneumatic Ball Valve FAQs
We typically need valve size, pressure rating, body and seat material (if known), media, line pressure, required fail position (fail-open / fail-close / fail-last), available air pressure and control philosophy (on/off or modulating).
Double-acting actuators use air to open and air to close. Spring-return actuators use air in one direction and a spring to move the valve to a defined fail-safe position on air failure.
Yes. VALSTEER pneumatic ball valves can be supplied as fully assembled packages, including actuator, SOV, AFR, limit switch box and basic fittings/tubing as configured in your enquiry or purchase order.
The required air pressure depends on the actuator size and torque required. Typical industrial ranges will be indicated in the actuator datasheet and confirmed during selection.
On selected combinations, pneumatic ball valves can be supplied with positioners for modulating service. This is subject to application review and actuator/positioner compatibility.
In many cases, yes, provided the valve has a suitable stem design and mounting pad, or can be adapted via a bracket and coupling. Details of the existing valve are required to confirm feasibility.
