VALSTEER Gate Valves : Precision Control for High & Low-Pressure Applications
Phoenix ValSteer is renowned for manufacturing high-quality Gate Valves, designed to operate efficiently under both high and low-pressure conditions. VALSTEER Gate Valves are engineered to meet the rigorous standards of API-600, ensuring optimal performance in a wide range of industrial environments.
Our VALSTEER Gate Valve Ranges
Rising Stem Gate Valve
Flexible Wedge Gate Valve
Through Conduit Gate Valve
Bolted Bonnet Gate Valve
Pressure Seal Bonnet Gate Valve
Technical Specification
Size
DN50-DN600
Pressure Rating
150#, 300#, 600#, 900#, 1500#
Design Standard
API 600, 6D & BS 1414
Design type
Bolted Bonnet and Pressure Seal Bonnet
End Connection
Flagged B16.5 RF/ RTJ/ BW and Vitualic
Wedge type
Flexible, Double Disc, Conduit, and Solid
Operation
Hand Wheel, Manual Gear, Electric, and Hydraulic
MOC
| BODY – BONNET | SEAT/DISC | STEM |
|---|---|---|
| CAST CARBON STEEL ASTM A216 GR.WCB/WCC | 13% Cr. S.S. | A 182 F6 |
| CAST STEEL ASTM A352 GR LCB AND LCC | A351 CF8 | A 182 F304 |
| ALLOY STEEL ASTM A217 GR WC1, WC4, WC5, WC6, WC9, WC11, C5 & C12 | 13% Cr. S.S/CF8/CF8M | A182 F6/F304/F316 |
| S.S 304/304L ASTM A351 GR.CF8/CF3 | A351 Gr. CF8/CF3 | A182 F304/304L |
| S.S 316/316L ASTM A351 GR.CF8M/CF3M | A351 Gr. CF8M/CF3M | A182 F316/316L |
| DUPLEX AND SUPER DUPLEX S.S. ASTM A 995 Gr. 1A, 1B, 1C, 2A, 3A, 4A, 5A, 6A | DUPLEX/SUPER DUPLEX S.S TO SUIT BODY | DUPLEX/SUPER DUPLEX S.S. |
| SUPER ALLOY STEEL- HASTELLOY Gr. B & C | HASTELLOY Gr. B & C | HASTELLOY Gr. B & C |
| INCONEL ASTM B564 UNS N06625 & 600 | UNS N06625 & 600 | UNS N06625 & 600 |
| FORGED ALLOY STEEL- ASTM A182 F11, F22 etc. | A182 F6/F304/316 | A182 F6/F304/316 |
| FORGED DUPLEX & SUPER DUPLEX STAINLESS STEEL ASTM A182 F51, F53, F555 etc. | A182 F51/F53/F55 etc. | A182 F51/F53/F55 etc. |
| FORGED STAINLESS STEEL ASTM A182 F304/304L/ F316/316L | F304/304L/F316/316L | F304/304L/F316/316L |
| DUCTILE IRON/SG IRON/C.I. OF DIFFERENT GRADES | 13%CR.SS/CF8/CF8M | A182 F6/F304/F316 |
Key Features of VALSTEER Gate Valve
- Versatile Application: Suitable for pressure from either side, ensuring total and tight isolation.
- Durability: Seal welded seat rings enhance safety and longevity.
- Material Diversity: Available in a wide range of materials to suit any application.
- Efficient Design: Straight-through flow design ensures no fluid turbulence and noise.
Why Choose VALSTEER Gate Valve?
- Innovative Solutions: VALSTEER Gate Valves are designed with the latest technology to ensure high performance and reliability.
- Quality Assurance: As an ISO 9001:2015 certified manufacturer, we adhere to the highest standards of quality and safety.
- Custom Engineering: We provide custom solutions tailored to meet your specific operational needs.
